JL24-20TKH 20-Core Straight PCB Socket Rectangular mili-tary Aviation Connector.
JL24-20TKH is a 20-core straight PCB socket rectangular aviation connector of the JL24 series. It features standard straight pin structure for easy PCB soldering and assembly. Equipped with high-performance gold-plated wire spring contacts, it ensures stable conduction, low signal loss and long plugging service life. With strong vibration resistance, impact resistance and anti-interference performance, it adopts high-quality insulating material with excellent temperature, moisture and corrosion resistance. Manufactured in accordance with mili-tary standards, it is compact in structure and firm in locking, widely used in industrial control, automation, avionics and precision instruments to provide reliable multi-circuit connection.
Specifications
| Specifications |
| Rated Current |
3A per contact |
| Rated Voltage |
300V AC |
| Contact Resistance |
≤10mΩ |
| Insulation Resistance |
≥5000MΩ (normal) |
| Withstanding Voltage |
1000V AC (normal) |
| Mechanical Life |
≥500 mating cycles |
| Operating Temperature |
-55°C ~ +125°C |
